SBNet: Sparse Blocks Network for Fast Inference

Mengye Ren^*,1,2, Andrei Pokrovsky^*,1, Bin Yang^*,1,2, Raquel Urtasun^1,2

¹Uber Advanced Technologies Group, Toronto ON, CANADA
²Department of Computer Science, University of Toronto, Toronto ON, CANADA
^*Equal contribution

Abstract

Conventional deep convolutional neural networks (CNNs) apply convolution operators uniformly in space across all feature maps for hundreds of layers - this incurs a high computational cost for real time applications. For many problems such as object detection and semantic segmentation, we are able to obtain a low-cost computation mask, either from a priori problem knowledge, or from a low resolution segmentation network. We show that such computation masks can be used to reduce computation in the high resolution main network. Variants of sparse activation CNNs have previously been explored on small scale tasks, and showed no degradation in terms of object classification accuracy, but often measured gains in terms of theoretical FLOPs without realizing a practical speed-up when compared to highly optimized dense convolution implementations. In this work, we leverage the sparsity structure of computation masks and propose a novel tiling-based sparse convolution algorithm. We verified the effectiveness of our sparse CNN on LiDAR based 3D object detection, and we report significant wall-clock speed-ups compared to dense convolution, as well as improved detection accuracy.

Full Paper

[pdf]

Code

[link]

Cite


@inproceeding{ren18sbnet,
  author    = {Mengye Ren and
               Andrei Pokrovsky and
               Bin Yang and
               Raquel Urtasun},
  title     = {SBNet: Sparse Blocks Network for Fast Inference},
  journal   = {Proceedings of the 2018 IEEE Conference on Computer Vision
               and Pattern Recognition, {CVPR}},
  year      = {2018},
}
